Charging crane
Lifting Capacity（T): 20+20ton To 110+110ton, 180/50ton, 240/80ton, 260/80ton And 300/80ton
Span（m): 30
Lifting Height(m): 30
Work Classifications: A7 \ A8
Introduction
As one of the series products of foundry cranes, charging cranes are very important in steel production. As crane equipment used in foundries and steel mills, in most cases, charging cranes are mainly used to transport molten metal. Charging cranes are sometimes called teeming cranes. Both the charging crane and the ladle crane are foundry cranes. The main difference between it and the ladle crane is that its main hoisting mechanism does not work completely independently, and both of its hooks need to have high loads. Ability.
It usually feeds the electric arc furnace in the charging workshop and can transport the molten iron to the continuous caster or the turret station of the ladle furnace, which is a heavy-duty continuous operation process.
As a special bridge crane, the main structure of the loading crane includes the box bridge, the lifting trolley, the driving system and the electrical device, and each of its components needs to be very good in terms of material and performance.
Charging crane
Applications: As crane equipment used in foundries and steel mills, in most cases, charging cranes are mainly used to transport molten metal. ect.
OEM and ODM accepted;
Lower price at same quality;
Drawing provided when need;
24 hours price provided;
Customization production, high efficiency;
Specification
| Lifting Capacity | T | 20+20ton To 110+110ton, 180/50ton, 240/80ton, 260/80ton And 300/80ton |
| Span | M | 30 |
| Lifting Height | M | 30 |
| Work Classifications | A7 \ A8 | |
Feature
The hoisting mechanism of the charging crane adopts a redundant system design to ensure the safety and reliability of hoisting liquid metal.
Install a monitoring system to monitor the working status of the crane in real time
Wireless transmission and electronic scale, real-time transmission of liquid metal weight.
Each crane is designed with an electrical room, and electric fans are installed in the electrical room to ensure the safe and reliable operation of electrical equipment.
The main and auxiliary trolleys realize unmanned automatic bag hanging, saving costs.
The overall design is light and compact.
Low height, light weight, small hook limit and large working range.
High quality accessories, durable, safe and reliable.
Maintenance and repair costs are low.
The total power of the crane is small and the energy consumption is low.
Frequency conversion speed regulation, stable up and down, small impact.
Case:
FAQ:
01How do I choose the right charging crane?
You can choose according to your needs, or you can consult our experts, we can provide you with the best solution for charging Crane.
02What are the application scenarios of charging crane?
It usually feeds the electric arc furnace in the charging workshop and can transport the molten iron to the continuous caster or the turret station of the ladle furnace, which is a heavy-duty continuous operation process.
